Wood Chemical Impregnation Treatment Plant
We at Wood Working Machinery are known for our superior quality machines used in the treatment of plywood and timber. For the production of the best quality wood on the market, the wood needs to undergo several treatments and we are supplying the best treatment plants for the same. Presently, we are one of the most eminent Wood Chemical Impregnation Treatment Plant Manufacturers, supplying in PAN India. We are producing these treatment plants to help industries get wood free from pests, termites, insects, and other wood fungus. This plant is widely used in different industries such as,
- Handicraft Industry
- Plywood Industry
- Flush door Treatment
- Cooling Tower Industry, Elo
- The Beneficial Features of The Multi Equipment Machinery Corp's Wood
- Treatment Plant
For the production of long-lasting wood products, it is essential to keep them free from such problems. That is why we at Wood Working Machinery are utilizing the best resources to produce wood treatment machines to help different industries. Our wood chemical impregnation treatment plant is suitable for using different types of chemical formulations for proper wood treatment. According to the type of wood and the treatment required one can utilize the kind of chemical they require. Being one of the top Wood Chemical Impregnation Treatment Plant Manufacturers, we always produce machines that are resistant to corrosion and chemicals for their proper utilization. We are producing units that are easy to install and can be processed with ease. Be it small-scale industries or large-scale industries, they can be installed at both places. The chemical impregnation process will help industries get highly durable and robust quality wood for several applications.
Use of Wood Chemical Impregnation Treatment Plant
Wood Working Machinery has been considered excellent in supplying Wood Chemical Impregnation Treatment Plant for many years. Though we mainly supply the plywood and handicraft industry. But other than that, these plants are also required in the construction industry, mining industry, agriculture industry, marine industry, transportation industry, and all the other industries where woodworking is required in large amounts.
Why choose us?
Wood Working Machinery has ISO approval for fabricating premium quality Wood Chemical Impregnation Treatment Plant. We have been into the manufacturing of different types of wood treatment plants for years and have in-depth knowledge about them. Right from the design of these machines to their final production and quality testing, we take care of everything. We are capable of supplying these wood treatment machines in bulk due to our extensive manufacturing unit and knowledgeable engineers. We are known for supplying well-certified wood chemical impregnation treatment plants for better preservation of wood. Being one of the leading Wood Chemical Impregnation Treatment Plant Manufacturers and suppliers, we are offering these at the best market prices.
Why Us!
- The horizontal pressure vessel placed above the underground constructed concrete storage tank. By this no pump is required to transport the solution from vessel to the storage tank, as it will be done with the help of gravity. It makes the plant very compact which minimizes the land area also.
- The plant is supplied as a 2 stage rapid & basic installation process: (A) Leveling on the concrete foundation (B) Connection to electricity and water. The installation is carried out within 3-4 hours. The plant can easily be re-located to another site as & when if required
- The piping connections with valves are fitted on the top of the treatment plant with electric motors, pressure compressor, vacuum compressor for easy operation and effortless supervision.
- The plant is manufactured with the best method of bolt locking system which is by far the most satisfactory & a safe design. The gate is fitted with 25mm thick high tensile rubber seal for a leak proof operation & the gate locking bolts are made out from 50.8mm thick Mild Steel Square for a secure operation.
- There is zero maintenance cost because of the following features:
- All Valves & components are of well-known standard 150 approved brands.
- 02 No. of bottom 3" Flange Type Extra Heavy Duty Ball Vales' are provided by us which a single valve cost between 15,000 to 20,000 INR included with the tank making us different from other suppliers as quality is our main priority.
- ISO approved well-known standard company pressure & vacuum compressors with replacement warranty are provided
- All pipings are with flange fitting type. 8 Fittings like gauge glass set are made of Stainless Steel & valves such as safety valve, check valve. gate valve etc are made of gun metal material.
WOOD CHEMICAL IMPREGNATION TREATMENT PLANT CAPACITY
- Multi Equipment Treatment Plant (MTP-10) having foliowing sizes horizontal pressure vessels with single side opening bolt locking system.
- Plant is suitable for process of pressure- vacuum pressure and alternative pressure cycles.
- Available is different sizes as per client's requirement
| S/No | Model No. | Capacity with & W/o Trolley SystemSize of Treatment Plant. | (Length x Width). | Required H.P for electric motors. pressure & vacuum compressors |
|---|---|---|---|---|
| 01 | MTP-12 | 75 C.F.T w/o trolley system | 12'LX4W | 05HP |
| 02 | MTP-16 | 100 C.FT w/o trolley system | 16"L x 4'W | 05HP |
| 03 | MTP-10 | 150 C.FT with Trolley system | 10'L x 5'W | 05HP |
| 04 | MTP-11 | 225 C.FT with trolley system | 12'Lx6'W | 7.5HP |
| 05 | MTP-21 | 300 C.FT with trolley system | 21'Lx5'W | 7.5HP |
| 06 | MTP-22 | 400 C.FT with trolley system | 21 L x 6'W | 10Hp |
